Low Current Consumption:As Low as 120 μA (typ) in Duty-Cycle Mode
Wide Supply Range: 2.3 V to 5.5 V
Programmable Gain: 1 V/V to 128 V/V
Programmable Data Rates: Up to 2 kSPS
16-Bit Noise-Free Resolution at 20 SPS
Simultaneous 50/60-Hz Rejection at 20 SPS with Single-Cycle Settling Digital Filter
Two Differential or Four Single-Ended Inputs
Dual-Matched Programmable Current Sources: 50 μA to 1.5 mA
Internal 2.048-V Ref: 5 ppm/°C (typ) Drift
Internal 1% Accurate Oscillator
Internal Temperature Sensor: 1°C (typ)
SPI-Compatible Interface
Package: TSSOP-16
